Lumin D3 Streamer
T3 Specification
  • DSD Support:
    • Up to DSD256, 1-bit, Stereo
  • PCM Support:
    • Up to 384kHz, 16–32-bit, Stereo
  • Analog Output Stage:
    • ESS SABRE32 ES9028Pro DAC chip
    • Balanced layout with high-quality components
    • Completely redesigned analogue buffer includes audiograde output capacitor and ultra-low-noise and high dynamic range
    • Discreet clock system for precision timing
  • Upsampling rates & bit depths:
    • DSD256 upsampling option for all files
    • PCM 384kHz upsampling option for all files
  • Digital Output Stage:
    • BNC SPDIF:
      • PCM 44.1kHz–192kHz, 16–24-bit
      • DSD (DoP, DSD over PCM) 2.8MHz, 1-bit
  • Power Supply:
    • Internal 100–240V AC auto-ranging
    • Low-noise
    • Shielded power supply compartment for reduced interference with delicate electronics
  • Physical:
    • Finish:
      • Black anodised aluminium
      • Raw anodised aluminium
      Dimensions
      • 300mm (W), 244mm (D), 60mm (H), 2.5kg

Lumin D3 Streamer

    • Streaming Protocol:

      • UPnP AV protocol with audio streaming extension (OpenHome)
      • Roon Ready
      • TIDAL Connect
      • Spotify Connect
      • AirPlay 2 compatible
      • Gapless Playback
      • On-Device Playlist

    • App Features:

      • Native support for TIDAL, MQA, Qobuz and TuneIn Radio.
      • Tidal MQA icons to identify high-res music
      • Qobuz high-res icons to identify high-res music
      • Volume control
      • High-resolution artwork
      • Artwork caching
      • Search
      • Multiple tag handling
      • Composer tag support
      • Album-grouping in playlist
      • Automatic internet links to artists/album/songs
      • Saving and restoring of playlists (including Tidal and Qobuz)

    • Supported Audio File Formats:

      • DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD)
      • PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF
      • Compressed (lossy) Audio: MP3
      • MQA

    • Input:

      • Ethernet RJ45 network 1000Base-T
      • USB storage, flash drive, USB hard disk (Single-partition FAT32, exFAT and NTFS only)

    • Analogue Audio Outputs:

      • XLR balanced, 6Vrms, pin 2 Hot
      • RCA unbalanced, 3Vrms

    • Supported Control Devices:

      • Apple devices. iOS 11.0 or later (List of supported devices)
      • Android devices. Android 4.0 (Ice Cream Sandwich) or later required

    • Other:

      • Leedh Processing lossless digital volume control
      • Programme of Continuous Development – Firmware-upgradable for further features and enhancements
